Electronic Factory Lab Pedestrian Electrostatic Human Body ESD Turnstyle
Technology Parameter Of GAT-ESD305 ESD Turnstyle
| 1 | Instrument Dimensions | 8 inch LCD monitor: display all info of users, like photo, name, card ID,depart, entry time,etc. |
| 2 | pedal size | (W) 400mmx (L) 420mmx (H) 20mm |
| 3 | Operating voltage | input AC220V output DC12V |
| 4 | Working hours | unlimited |
| 5 | Environmental conditions | Humidity: 0%~90%, Temperature: 5C°~ 40°C |
| 6 | Automatically store records and ESD test data (except client mode), recording information up to 100,000 or more. |
| 7 | Test Range and Accuracy (Note: The ESD checker meets the standards of other countries. The upper and lower limit values of the test range can be adjusted according to customer requirements.) |
| Left shoe setting 0.01-1000MΩ,Accuracy ±5% Right shoe setting 0.01-1000MΩ,Accuracy ±5% Wrist-strap setting 0.1-35MΩ,Accuracy ±5% |
ESD Turnstyle Features
It can be used to save data online, with signal output, 8 inch display monitor, included related software, tester and voice prompts (additional), and employee card access control.
1. ESD equipment can be quickly tested, and three independent devices (Left Shoes, Right Shoes, Wrist Strap) be completely ESD tested at one time.
2. Just install SQL Server2000/2008 and run the access control management software system on any computer in your
company.
3. Through TCP/IP communication technology, you can connect 255 human body comprehensive testing equipment (255 sets of Flap Turnstile / Tripod Turnstiles or other types). To monitor employees' compliance with anti-static requirements in real time.
| Technical Parameters of ESD Turnstyle |
| 1 | Power | AC220(or 110v) ±10V,50HZ |
| 2 | Operating temperature | -15°C--75°C |
| 3 | Relative Humidity | ≤95%, No Condensation |
| 4 | Pathway length | 60cm |
| 5 | Passing Speed | 30~40 persons/min(IC Card) |
| 6 | Motor | 0.5NM/24V(Fully Automatic) |
| 7 | Input Connection | +12V Level Signal or Pulse Wide>100ms DC12V |
| 8 | Communication Connection | RS485 Communication Module Standard. |
| 9 | Material | SUS304,thickness is no less than 1.3mm |
| 10 | Protection Grade | IP54 |
| 11 | Colour | SSB(US32D)- Stainless Steel Brushed / Powder Coating(Optional) |
Working mode Instruction
① Simultaneously detect hands and feet. This mode is suitable for line operators;
② Only detect the feet, this mode is suitable for those who need to enter the workshop, but do not directly contact the product such as QC, warehouse manager, etc.;
③ Only detect the hand, this mode is suitable for assembly line or logistics;
④ Free test card, applicable to the boss/customer inspection workshop, passing directly via swiping card.
Package:inside carton,outside crate package or closed wooden package
